Highly Sensitive Azo Test Strips for Metal Ion Detection

Introduction to Azo Test Strips and Their Applications

Azo test strips have emerged as a vital tool in the detection of metal ions in various environments, primarily due to their high sensitivity and reliability. These strips utilize azo compounds that change color in response to the presence of specific metal ions, enabling rapid and straightforward analysis. Azo compounds are characterized by the presence of a nitrogen-nitrogen (N=N) bond, which is crucial for their chromogenic properties. This property is leveraged in many applications, including environmental monitoring, food safety, and clinical diagnostics.

Nickel, in particular, has gained attention due to its widespread use in industrial applications and its potential toxicity to both humans and the environment. The permissible limit for nickel in drinking water, as specified by the United States Environmental Protection Agency, is 1.2 μM (EPA, 2021). Therefore, the development of sensitive detection methods for nickel is crucial for ensuring safety and compliance with regulatory standards.

Synthesis of Azo Compounds for Test Strips

The synthesis of azo compounds for use in test strips typically involves a two-step process: diazotization and diazo coupling. Diazotization involves treating an aromatic amine with sodium nitrite in an acidic medium, thereby forming a diazonium salt. This salt can then react with various coupling components, such as 8-hydroxyquinoline, to form colored azo products.

For instance, compounds like 5-[2-(4′-methoxy-2′-nitrophenyl)diazen-1-yl]quinolin-8-ol (S4) have been synthesized through these methods, resulting in vibrant colors that are indicative of the compound’s interaction with specific metal ions. The synthesis is typically optimized by adjusting parameters such as pH, solvent composition, and reaction time to achieve the desired sensitivity and specificity for metal detection.

Characterization Techniques for Azo Test Strips

Characterization of the synthesized azo compounds is essential to confirm their identity and assess their suitability for use as chemosensors. Techniques such as UV-Vis spectroscopy, FTIR, NMR, and ESI-MS are commonly employed to analyze the structural properties of these compounds.

For example, UV-Vis spectral data reveal that certain azo compounds can detect Ni²⁺ ions by producing observable color changes, ranging from violet to orange. The limits of detection for these compounds generally fall within the range of 0.012–0.038 μM, significantly lower than the permissible levels for nickel in drinking water. Additionally, the accuracy and precision of these chemosensors can be validated through comparative studies using inductively coupled plasma mass spectrometry (ICP-MS).

Table 1: Detection Limits of Azo Compounds for Ni²⁺ Detection

Optimizing Azo Test Strips for Nickel Detection

The optimization of azo test strips for nickel detection involves several factors, including solvent selection, pH adjustment, and reaction time. For successful detection, a solvent system of ethanol and water (in a 4:1 ratio) is often employed, with pH levels set to 4 for certain compounds to enhance colorimetric responses.

Through systematic studies, it has been established that the optimal reaction time for color change occurs within two minutes of mixing the test solutions. This rapid response time enhances the practicality of azo test strips in field settings.

Table 2: Optimized Conditions for Azo Test Strips

Performance Evaluation of Azo Test Strips in Water Analysis

Performance evaluation of the azo test strips in real water samples, including tap and underground water, demonstrates their effectiveness in detecting nickel ions. The spiked recovery studies reveal that the chemosensors maintain high accuracy and precision, with relative errors and precisions remaining below 5% and 4%, respectively. This performance indicates that azo test strips can function as reliable alternatives to traditional detection methods.

Additionally, the colorimetric response of the test strips changes from orange to violet upon nickel exposure, which can be visually assessed. This property not only simplifies the detection process but also allows for immediate interpretation of results, making azo test strips suitable for on-site applications.

Future Prospects of Azo Test Strips in Environmental Testing

The future of azo test strips in environmental testing appears promising due to their simplicity, cost-effectiveness, and sensitivity. As environmental regulations become stricter, the demand for rapid and accurate detection methods for toxic metals like nickel is anticipated to rise.

Future research may focus on expanding the range of detectable metal ions, improving the stability of azo compounds, and enhancing the overall sensitivity and specificity of the test strips. Additionally, integrating these chemosensors into portable devices could facilitate widespread use in various fields, including water quality monitoring, industrial applications, and food safety assessments.

FAQ

What are azo test strips used for?
Azo test strips are primarily used for the detection of metal ions, such as nickel, in various environments including water quality testing and food safety assessments.

How do azo compounds work in test strips?
Azo compounds change color in response to the presence of specific metal ions, allowing for visual detection and analysis.

What are the optimal conditions for nickel detection using azo test strips?
Optimal conditions include using a solvent ratio of 4:1 ethanol to water, maintaining a pH of 4 for certain compounds, and allowing a reaction time of two minutes.

What is the limit of detection for nickel using azo test strips?
The limits of detection for nickel using azo test strips typically range from 0.012 to 0.038 μM, which is significantly lower than the permissible levels in drinking water.

Are azo test strips environmentally friendly?
Yes, azo test strips, especially when synthesized using green chemistry methods, can be environmentally friendly alternatives to traditional detection methods that may involve hazardous chemicals.

References

1. Environmental Protection Agency. (2021). National Primary Drinking Water Regulations: Nickel
2. Olaleye, S. O., Idowu, S. O., & Khan, M. A. (2025). New 8-hydroxyquinoline-based azo dyes as highly sensitive colorimetric chemosensors for nickel cation. RSC Advances
3. Kaczmarek, M., & Białkowska, A. (2025). Enzymatic functionalization of bacterial nanocellulose: current approaches and future prospects. Journal of Nanobiotechnology. https://doi.org/10.1186/s12951-025-03163-x
4. Li, C., Xu, T., Hou, G., Wang, Y., & Fu, Q. (2025). Engineering dual p–n-type CuI with significant enhanced performance for advanced thermoelectric applications. Journal of Materials Chemistry A. https://pubmed.ncbi.nlm.nih.gov/11798337/
5. Faraco, T., et al. (2022). Composite Films Based on Linear Polyethyleneimine Polymer and Starch or Polysaccharides from DDGS: Synthesis, Characterization, and Antimicrobial Studies. Molecules. https://doi.org/10.3390/polym17040458
